40G QSFP+ Optical Transceiver FR4 2km Duplex LC SMF Modules

Certification : CE, FCC, ROHS, ISO9001, ISO14000, MSDS, REACH, CP65, TUV, UL

Place of Origin : China

MOQ : 1 pcs

Price : negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 50,000pcs/month

Delivery Time : 1-5 work days

Packaging Details : Single Package,10pcs per Tray,100-500pcs per Carton

Form Factor : QSFP+

Max Data Rate : 41.25Gbps

Wavelength : 1310nm

Distance : 2km

Connector : Duplex LC

Media : SMF

Transmitter Type : DFB CWDM

Receiver Type : PIN

TX Power : -9.4~-0.5dBm

Receiver Sensitivity : <-14.4dBm

Receiver Overload : 0.5dBm

Power Consumption : ≤2.5W

Extinction Ratio : >4.5dB

Temperature : C-Temp & I-Temp

Protocols : OTN OTU3, 40G Ethernet, Fiber Channel, SATA/SAS3, MSA

Warranty : 3 Years

Compatible Brand : Cisco,Arista,Juniper,Brocade,H3C,Dell,Extreme,HW,Intel,Netgear,IBM,Mellanox,Avaya,Alcatel-Lucent,D-Link,Ubiquiti&Generic

Contact Now

40G QSFP+ Optical Transceiver FR4 2km Duplex LC SMF modules for Brocade compatible

Features

4 CWDM lanes MUX/DEMUX design
Transmission data rate up to 11.3Gbps per channel
Duplex LC connector
Hot Pluggable QSFP+ form factor
Up to 2 km transmission
Compatible with RoHS
Single +3.3V power supply
Real Time Digital Diagnostic Monitoring
Operating case temperature: 0 to +70°C

Applications

40GBASE-LR4 Ethernet
Switch, router and HBAs
Data Center Interconnect
40G Campus Link

Description

The QSFP+ FR4 transceivers are high performance, cost effective modules supporting data rate of 40Gbps and 10km transmission distance with SMF.

The transceiver consists of three sections: 4 inputs channels (ch) of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single channel for 40Gb/s optical transmission; on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data; and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with 40GBASE-LR4 of IEEE802.3ba standard and SFF-8436 specification.

40G QSFP+ Optical Transceiver FR4 2km Duplex LC SMF Modules Images
